Project Description

HUAYO Peanut Shelling Machine is specifically designed to separate peanuts from pods after harvest. It is also called Goundnut Shelling Machine, Peanut Sheller.

The Peanut shelling machine is designed with two vibrating screen, which will remove the impurity and get clean Peanut directly.  It is composed of a frame, a fan, a rotor, a single-phase motor, a screen (two types of large and small), a hopper, a vibrating screen, a V-belt wheel and a driving V-belt, etc.

How a Peanut Shelling Machine Works:

  1. Feeding the Crop: The harvested peanut plants, with peanuts still attached to the vines, are fed into the machine.
  2. Threshing Process: Inside the machine, rotating drums or beaters gently break open the peanut pods to release the peanuts without damaging the kernels.
  3. Separation: The machine uses air blowers, sieves, or other separation mechanisms to cleanly separate the peanuts from the husks, vines, and other debris.
  4. Output: Cleaned peanuts are collected for drying, processing, or storage, while the waste material (husk and straw) is discarded or used for other purposes like animal feed.

Technical Parameter

Model HPT-600
Structural style Double-cylinder
Productivity 500-600 kg/h
Motor 2.2 kw 220v 50hz
Screening type Gravity sieve
Threshing rate > 98%
Peanut breaking rate < 3%
Outsize 1330X750X1570 mm
Weight 200 kg

Pictures

Working with conveyor, the Peanut Shelling Machine can shell peanuts automaticlly to improve working capacity.

Diesel engine Peanut Thresher

How does the Peanut Threshing Machine work ?

Peanut after threshing
